Taarup 9032-9035

Return to all products

Model Taarup 9032-9035

Compact Single Rotor Rakes

Kverneland Taarup offers several compact single rotor rakes, designed for use on low horsepower tractors, but which still deliver considerable working width. Kverneland Taarup single rotor rakes offer working widths of 3.2 - 4.7 m. With the option of pivoting, fixed three-point linkage mounting and a trailed version, there is a model to suit all needs. All rakes (except 9442T) have mechanical height adjustment via a crank, with the possibility of adjusting to the individual field conditions.

The Advantages:

  • Compact and light design that can be operated by smaller tractors.
  • CompactLine gearbox with cam discs and tine arm bearing running permanently in oil
  • Curved tine arms for cleaner raking performance and better swath formation.
  • High number of options are available, such as tandem axles, oscillation dampers and a third wheel.

Technical Specifications:

  Working Width No of Tine Arms Weight
9032 3.20m 9 320kg
9035 3.50m 10 420kg
9439 3.90m 11 460kg
9442 T 4.20m 11 570kg
9443 4.30m 12 490kg
9447 T 4.70m  12 665kg
